Brass Barrell Union Female

Brass Barrel Union Female (FF)

The Brass Barrel Union Female (FF) is a high-quality BSP fitting designed to securely join sections of pipework while allowing for easy disassembly when required. With female threads at both ends, this fitting is ideal for applications where maintenance or part replacement may be needed without disturbing the entire pipeline.

Key Features:

• Material: Manufactured from durable DZR (dezincification-resistant) brass, built to withstand Australia’s tough conditions
• Thread Type: BSP tapered thread for a reliable and leak-free connection
• Applications: Suitable for both drinking water and gas systems
• Convenience: Allows part of the pipework to be disconnected without dismantling the whole line
• Strength & Durability: Provides excellent resistance to corrosion, mechanical stress, and chemicals
• Compliance: WaterMark approved and manufactured to AS3688 standards
• Performance: Maximum working temperature of 60°C and maximum pressure rating of 2000 kPa
• Installation: Use with Teflon tape and sealing paste (e.g. Mirror Paste) for a consistent watertight seal

Why Choose Brass Barrel Unions?

Screwed brass fittings offer long-lasting durability, safety, and compliance with Australian Standards. With the use of DZR brass, these unions resist corrosion and dezincification, ensuring reliable performance in harsh environments. Many fittings are made from recycled brass, with every batch tested for compliance, so you can trust in their quality and strength.

Important: A licensed plumber is required for installation if this fitting is used in pipework connected to mains water or gas.

Available Sizes:

• FSB4403 — Brass Barrel Union FF 12mm
• FSB4404 — Brass Barrel Union FF 20mm
• FSB4405 — Brass Barrel Union FF 25mm
• FSB4410 — Brass Barrel Union FF 32mm
• FSB4415 — Brass Barrel Union FF 40mm
• FSB4420 — Brass Barrel Union FF 50mm
