Civilcast 900 X 900 X 900Mm D Precast Concrete Pit With Ko 927Kg Pt99 900

Civilcast 900 x 900 x 900mm D Precast Concrete Pit with KO – 927kg (PT99-900)

The Civilcast 900 x 900 x 900mm D Precast Concrete Pit (PT99-900) is a heavy-duty stormwater and drainage pit designed for large-scale civil, commercial, and infrastructure applications. Manufactured by Civilcast under strict quality-controlled factory conditions, this precast unit delivers consistent performance, high structural integrity, and long-term durability in demanding site environments.

Constructed from reinforced concrete with internal steel reinforcement, this pit is engineered to withstand significant ground pressure, traffic loading, and environmental exposure. Rated to Class D, it is suitable for applications requiring robust load-bearing capacity and reliable long-term performance in stormwater and utility systems.

The integrated knockouts (KO) allow for flexible pipe entry points, making installation and system integration more efficient across a wide range of drainage configurations. This modular design supports compatibility with risers, grates, and other stormwater components, enabling adaptable installation on complex sites.

Weighing approximately 927kg, the unit provides excellent stability once installed, reducing the risk of movement or displacement. It is also designed with lifting points to assist with safe handling and faster installation on-site, helping improve efficiency and reduce labour costs.

Features & Benefits:

• 900 x 900 x 900mm precast concrete pit (PT99-900)
• Manufactured under controlled factory conditions for consistent quality
• Class D load rating for heavy-duty civil applications
• Reinforced concrete construction with internal steel reinforcement
• Integrated knockouts (KO) for flexible pipe connection options
• Suitable for stormwater and drainage infrastructure systems
• Complies with Australian Standards (AS 3600 and relevant authority requirements)
• Heavy-duty 927kg unit for maximum stability and durability
• Designed with lifting points for safe and efficient installation
• Compatible with modular drainage components (grates, risers, surrounds)
• High resistance to load stress and environmental exposure

A premium precast drainage solution for engineers, contractors, and civil works requiring high-capacity stormwater infrastructure with long-term reliability and performance.
