Rinnai Heavy Duty CF HWS Condensing 32L Internal Preset 50°C – Suitable for NG or LPG Install

Groundbreaking Technology
The Rinnai HDC32i (Internal) Heavy Duty Continuous Flow Hot Water System is the first of its kind in Australia, combining dual stainless steel heat exchangers to maximise heating output from every mega joule of gas. This delivers an impressive thermal efficiency of 97%. The system also features revolutionary surface burner technology, an Australian first, providing reliable, high-performance hot water for demanding internal applications.

Flexible Installation
This room-sealed appliance uses a co-axial flue design with a maximum flue run of up to 42 metres, giving class-leading installation flexibility. Ideal for childcare centres, laundromats, high-usage amenities, and factories, it ensures dependable hot water supply while maintaining safety and energy efficiency.

Key Features & Benefits:

• 97% thermal efficiency – Internal model
• Revolutionary surface burner technology – Australian first
• 56kW output capacity
• 7.0 Star equivalent energy rating
• High temperature safety cut-out
• Dual stainless steel heat exchangers
• Top-down surface burner technology
• Heat exchange bypass technology – Maintains perfect temperature with reduced pressure loss
• Compatible with Rinnai Cascade staging system
• In-built controller – Displays water temperature and system status
• BMS (Building Management System) fault option
• Push-button PCB control – Simplifies installation setup
• High altitude function – Install up to 2,000 metres above sea level
• Fuel sensing technology – Compatible with both Natural Gas and LPG
• Anti-frost protection – Down to -20°C
• Preset temperatures available – 50°C and 75°C

Ideal For:

• Caravan parks
• Childcare centres
• Butchers
• Laundromats
• Small amenity blocks
• Factories
• High-temperature wash down areas

Warranty:

• 5 years – Heat exchanger
• 3 years – Parts & labour
